Conveyor Belt for Printing Machine Guide

Product Features:
Good specification and stability, quick debugging, small elongation of the guide belt during operation, basically no shrinkage phenomenon, no bell mouth, continuous and stable operation of the upright device when it is not working, smooth surface, no depression, strong durability.

Product Usage:
The printing guide belt is used in textile flatbed/rotary screen printing machines, and the requirements are very strict. The printing machine is one of the key equipment in the printing and dyeing industry, and the printing guide belt is the core part of the printing machine. Therefore, the quality of the printing guide belt directly determines the quality of the printing products.
  • Conveyor Belt for Printing Machine Guide
  • Conveyor Belt for Printing Machine Guide
  • Conveyor Belt for Printing Machine Guide

Advantage:

RELATED PRODHETS:

Performance
Part Number Specification Cloth thickness(g/m2) Thickness/mm The secret/in Weft density/in Warp Specifications Weft specification Shrink/% Weft contraction/%
13540A236C10 F13540A236 893 1.4 135 40
1000D/100S
1000D/100Z
Aramid 1500D/80S
Aramid 1500D/80Z
PET0.3 14 0.2
14340A225C15 14340A225 1300 1.8 143 40 1000D/100S
1000D/100Z
1000D/100S
2000D/60S
2000D/60Z
PET0.5 22 0.2
160400F5CC02 F16040 1060 1.2 160 40
500D/100S
500D/100Z
Aramid 1500D/80S
Aramid 1500D/80Z
PET0.3 14 3.1
16040LF5CC16 F16040-L 725 1 500D/100S
500D/100Z
Aramid 1000D/100S
Aramid 1000D/100Z
PET0.3 16 0

DIMENSION Drawing:
